• Biocompatible
• High Flexural Strength
• Ultra-Fast Printing
• Excellent Dimensional Stability
• Eliminates Need for Stone Models
• Long Shelf Life

Arma Dental 3D Printing Resin - Impression Tray in Blue is a high-performance, biocompatible resin specifically engineered for creating customized dental trays. Its durable composition ensures it can handle the forces involved in patient impressions, providing reliable and robust results. The resin features ultra-fast printing capabilities, eliminating the need for traditional stone models. With high flexural strength (143.03 MPa) and excellent dimensional stability, it enhances impression accuracy and overall performance. Compatible with DLP and LCD 3D printers operating at 385/405 nm, this resin offers a long shelf life and resists phase separation during storage.

• Type: Dental 3D Printing Resin
• Volume: 1 KG
• Flexural Strength: 143.03 MPa
• Elasticity Modulus: 2640.76 MPa
• Viscosity: 470 mPa.s
• Elongation at Break: 3.41 mm
• Compatible with: DLP and LCD 3D printers (385/405 nm)
• Color: Blue
• Shelf Life: Long, with phase separation eliminated during storage
• Compatible printer: ASIGA - ALL MODELS
• VELTZ - ALL MODELS
• ACKURETTA - SOL
• ACKURETTA - DENTIQ
• SHINNING 3D - ACCUFAB
• SHINNING 3D - ACCUFAB D1
• SPRINTRAY - ALL MODELS
• RAYSHAPE
• RAPIDSHAPE - ALL MODELS
• SILADENT - ALL MODELS
• DENTAFAB - SEGA
• CREALITY - ALL MODELS
• PHROZEN - TÜM MODELLER
• ANYCUBIC - ALL MODELS
• ELEGOO - ALL MODELS
• NOVA3D - ALL MODELS
• UNIZ - ALL MODELS

• Printer Preparation:
  • Ensure your DLP or LCD printer is properly set up and calibrated according to the manufacturer's instructions.
• Resin Handling:
  • • Shake the Arma 3D Printing Resin bottle well before each use to ensure uniform consistency and avoid settling of pigments.
• Printing Setup:
  • • • Pour the resin into the printer’s resin tank, making sure it is filled to the recommended level. Avoid overfilling to prevent spills and ensure optimal printing conditions.
• Printing Parameters:
  • • • • Adjust printer settings such as layer thickness and exposure time according to the specific requirements for dental impression trays and the capabilities of your printer. Follow any recommended settings provided by Arma for best results.
• Printing Process:
  • • • • • Initiate the printing process. Keep an eye on the printer to monitor for any potential issues during printing, such as warping or incomplete layers.
• Post-Processing:
  • • • • • • Once the printing is complete, carefully remove the printed impression tray from the build platform. Rinse the tray thoroughly in a cleaning solution that is compatible with resin-based prints to remove any uncured resin.
• Curing:
  • • • • • • • Cure the rinsed impression tray under UV light, following the manufacturer’s guidelines for time and intensity to achieve optimal mechanical properties and ensure biocompatibility.
• Finishing:
  • • • • • • • • If needed, polish the cured impression tray for a smooth finish. Depending on the application, you may also choose to stain or glaze the tray for aesthetic or functional purposes.
• Storage:
• • • • • • • • • • Store any unused Arma 3D Printing Resin in a cool, dry place away from direct sunlight to maintain its properties and shelf life. Ensure the bottle is tightly sealed to prevent contamination.

• Country of Origin: Made in Turkey
• Manufacturer: Arma Dental
